Understand the WordPress Database Structure Through a Peewee Model

While developing an application with Python’s Tornado framework, I wanted to refer to the WordPress database structure, so I used a tool to convert the WordPress database into Peewee models. From that model output, we can understand the WordPress database structure very conveniently, and we can even use it directly inside the Peewee ORM if needed. I am sharing it here for reference.

from peewee import *

database = MySQLDatabase('www', **{'user': "'root'"})

class UnknownField(object):
    pass

class BaseModel(Model):
    class Meta:
        database = database

class WpCommentmeta(BaseModel):
    comment = BigIntegerField(db_column='comment_id')
    meta = BigIntegerField(db_column='meta_id', primary_key=True)
    meta_key = CharField(max_length=255, null=True)
    meta_value = TextField(null=True)

    class Meta:
        db_table = 'wp_commentmeta'

class WpComments(BaseModel):
    comment = BigIntegerField(db_column='comment_ID', primary_key=True)
    comment_agent = CharField(max_length=255)
    comment_approved = CharField(max_length=20)
    comment_author = TextField()
    comment_author_ip = CharField(db_column='comment_author_IP', max_length=100)
    comment_author_email = CharField(max_length=100)
    comment_author_url = CharField(max_length=200)
    comment_content = TextField()
    comment_date = DateTimeField()
    comment_date_gmt = DateTimeField()
    comment_karma = IntegerField()
    comment_parent = BigIntegerField()
    comment_post = BigIntegerField(db_column='comment_post_ID')
    comment_type = CharField(max_length=20)
    user = BigIntegerField(db_column='user_id')

    class Meta:
        db_table = 'wp_comments'

class WpLinks(BaseModel):
    link_description = CharField(max_length=255)
    link = BigIntegerField(db_column='link_id', primary_key=True)
    link_image = CharField(max_length=255)
    link_name = CharField(max_length=255)
    link_notes = TextField()
    link_owner = BigIntegerField()
    link_rating = IntegerField()
    link_rel = CharField(max_length=255)
    link_rss = CharField(max_length=255)
    link_target = CharField(max_length=25)
    link_updated = DateTimeField()
    link_url = CharField(max_length=255)
    link_visible = CharField(max_length=20)

    class Meta:
        db_table = 'wp_links'

class WpOptions(BaseModel):
    autoload = CharField(max_length=20)
    option = BigIntegerField(db_column='option_id', primary_key=True)
    option_name = CharField(max_length=64)
    option_value = TextField()

    class Meta:
        db_table = 'wp_options'

class WpPostmeta(BaseModel):
    meta = BigIntegerField(db_column='meta_id', primary_key=True)
    meta_key = CharField(max_length=255, null=True)
    meta_value = TextField(null=True)
    post = BigIntegerField(db_column='post_id')

    class Meta:
        db_table = 'wp_postmeta'

class WpPosts(BaseModel):
    id = BigIntegerField(db_column='ID', primary_key=True)
    comment_count = BigIntegerField()
    comment_status = CharField(max_length=20)
    guid = CharField(max_length=255)
    menu_order = IntegerField()
    ping_status = CharField(max_length=20)
    pinged = TextField()
    post_author = BigIntegerField()
    post_content = TextField()
    post_content_filtered = TextField()
    post_date = DateTimeField()
    post_date_gmt = DateTimeField()
    post_excerpt = TextField()
    post_mime_type = CharField(max_length=100)
    post_modified = DateTimeField()
    post_modified_gmt = DateTimeField()
    post_name = CharField(max_length=200)
    post_parent = BigIntegerField()
    post_password = CharField(max_length=20)
    post_status = CharField(max_length=20)
    post_title = TextField()
    post_type = CharField(max_length=20)
    to_ping = TextField()

    class Meta:
        db_table = 'wp_posts'

class WpTermRelationships(BaseModel):
    object = BigIntegerField(db_column='object_id', primary_key=True)
    term_order = IntegerField()
    term_taxonomy = BigIntegerField(db_column='term_taxonomy_id')

    class Meta:
        db_table = 'wp_term_relationships'

class WpTermTaxonomy(BaseModel):
    count = BigIntegerField()
    description = TextField()
    parent = BigIntegerField()
    taxonomy = CharField(max_length=32)
    term = BigIntegerField(db_column='term_id')
    term_taxonomy = BigIntegerField(db_column='term_taxonomy_id', primary_key=True)

    class Meta:
        db_table = 'wp_term_taxonomy'

class WpTerms(BaseModel):
    name = CharField(max_length=200)
    slug = CharField(max_length=200)
    term_group = BigIntegerField()
    term = BigIntegerField(db_column='term_id', primary_key=True)

    class Meta:
        db_table = 'wp_terms'

class WpUsermeta(BaseModel):
    meta_key = CharField(max_length=255, null=True)
    meta_value = TextField(null=True)
    umeta = BigIntegerField(db_column='umeta_id', primary_key=True)
    user = BigIntegerField(db_column='user_id')

    class Meta:
        db_table = 'wp_usermeta'

class WpUsers(BaseModel):
    id = BigIntegerField(db_column='ID', primary_key=True)
    display_name = CharField(max_length=250)
    user_activation_key = CharField(max_length=60)
    user_email = CharField(max_length=100)
    user_login = CharField(max_length=60)
    user_nicename = CharField(max_length=50)
    user_pass = CharField(max_length=64)
    user_registered = DateTimeField()
    user_status = IntegerField()
    user_url = CharField(max_length=100)

    class Meta:
        db_table = 'wp_users'
